สนามพาเดลสำเร็จรูป

ITEM

DESCRIPTION

Steel Structure

1. Steel Frame
Column/column of fence frame: 100 * 100 * 3mm, height:3m

2. Beam
Upper beam: 100mm * 100mm * 3mm, length: 5m * 2
Bottom beam: 100mm * 50mm * 3mm, length: 5m * 2

3. Fence Frame
Fence: 1m * 2m (42 pieces in total)/1m * 4m (2 pieces in total)
Mesh diameter: 4mm
Mesh frame size: 50mm * 30mm
Mesh hole: 50*50mm

4. Auxiliary Columns

Net column: 100mm * 50mm * 3mm, height: 970mm
Lamp column: 100mm * 50mm * 3mm,height: 3m
Bolt: 304 stainless steel
Process: Hot Galvanizing
Color: Custom

Upper beam: 100mm * 100mm * 3mm, length: 5m * 2;
Bottom beam: 100mm * 50mm * 3mm, length: 5m * 2;
Fence frame:
Fence: 1m * 2m (42 pieces in total)/1m * 4m (2 pieces in total);
Mesh diameter: 4mm; Mesh hole size: 50mm * 50mm;
Net column:
Size: 100mm * 50mm * 3mm, height: 970mm;
Lamp column: 100mm * 50mm * 3mm,height: 3m;
Bolt: 304 stainless stee

Tempered Glass

Thickness:12mm
Size:2m*3m*18 pieces
Weight:175kg/piece
Package: Wood Carton
Finish: Hole drilled

Artificial Turf

MONDOTURF NSF SUPERCOURT XN
Raw Material: 100% PE
Dtex:9000D
Height: 12 mm
Density: 46200

LED Light

8 SETS Flood LED
200W
Phillips led chips
Lumen:26000
IP67 Water-proof

Net

Length: 9950mm
Height: 970mm
Material: PP
Mesh: 45mm
